Description
| Part Number | Thread inch | Hose I.D inch | A | E | W inch | H inch | B | |||
| inch | A mm | inch | mm | inch | mm | |||||
| 1J543-4-4 1J543-6-4 1J543-6-6 | 1/4 3/8 3/8 | 9/16×18 11/16×16 11/16×16 | 1/4 1/4 3/8 | 2.07 2.12 2.40 | 53 54 61 | 1.26 1.50 1.50 | 32 38 38 | 11/16 13/16 13/16 | 1.32 1.37 1.37 | 34 35 35 |
| 1J543-6-6-SM 1J543-8-6 1J543-8-8 | 3/8 1/2 1/2 | 11/16×16 13/16×16 13/16×16 | 3/8 3/8 1/2 | 2.40 2.48 2.59 | 61 63 66 | 1.50 1.61 1.61 | 38 41 41 | 22 mm 15/16 15/16 | 1.37 1.45 1.33 | 35 37 34 |
| 1J543-10-8 1J543-10-10 1J543-10-12 | 5/8 5/8 5/8 | 1×14 1×14 1×14 | 1/2 5/8 3/4 | 2.74 2.97 3.12 | 70 75 79 | 1.85 1.85 1.88 | 47 47 48 | 1-1/8 1-1/8 1-1/8 | 1.48 1.53 1.68 | 38 39 43 |
| 1J543-12-12 1J543-16-16 1J543-20-20 | 3/4 1 1-1/4 | 1-3/16×12 1-7/16×12 1-11/16×12 | 3/4 1 1-1/4 | 3.49 4.86 4.89 | 89 123 124 | 2.28 2.78 3.09 | 58 71 78 | 1-3/8 1-5/8 1-7/8 | 2.05 3.27 3.20 | 52 83 81 |
1J543 Crimp Hydraulic Hose Fittings Video
The crimp hydraulic hose fittings manufacturing process video gives you a better understanding of Topa’s factory and level of expertise.
As the video unfolds, you will see the entire process of one piece fitting from raw material cutting to completion. We use the highest quality carbon and stainless steel and specialized automated processes to ensure our products meet your standards.
Ready to experience quality service? Visit Topa today to learn more about our line of premium hydraulic fittings. Let Topa help you make a better choice.
