3 Stage DAT Hydraulic Cylinder

Nested Barrels: The cylinder comprises three barrels, each nested within the other. The smallest barrel extends first, then the middle, and then the largest.

Individual Pistons: Each stage has its piston, precisely fitted within its respective barrel.

Connected Rods: The piston rods are interconnected, ensuring a coordinated and smooth extension and retraction of the stages.

Separate Chambers: Each stage has distinct hydraulic chambers. The fluid’s pressure manipulates the movement of the pistons.

Fluid Ports: These are strategically placed for efficient fluid flow, crucial for the hydraulic operation of the cylinder.

Barrel: Shields the internal components from external elements and impacts.


The DAT 3 stage hydraulic cylinder is designed for tasks requiring extended reach and precise control. This cylinder extends in three stages, giving it a much longer reach compared to its retracted length. This is perfect for applications needing a long extension but limited space when retracted.

Despite its compact design, it can exert a significant amount of force, making it ideal for heavy lifting and pushing tasks. The stages extend one after another, starting from the innermost. This sequential movement ensures stability and control during operation.

The multistage hydraulic cylinder operates using hydraulic fluid. When you apply pressure to the fluid, it causes the stages to extend. The extension and retraction of the stages are smooth and controlled, allowing for precise movements.


Extended Reach: Offers a longer extension than standard cylinders, ideal for deep or far-reaching operations.

Compact Design: Remains short when retracted, saving space in machinery and systems.

High Force Output: Capable of exerting significant power, suitable for heavy-duty tasks.

Smooth Operation: Ensures controlled and stable movement, enhancing precision.

Durable Construction: Built to last, even in harsh working environments.


Construction Machinery: Used in equipment like cranes and excavators for extended reach in building and demolition.

Material Handling: Ideal for forklifts and loaders where space efficiency and reach are crucial.

Transportation: Essential in the design of multi-stage lifting systems in vehicles like dump trucks.

Agricultural Equipment: Used in machinery requiring extended reach for tasks like harvesting and plowing.

Mining Operations: Employed in drilling and excavation equipment for its power and reach capabilities.

DAT 3 Stage Hydraulic Cylinder

Topa assembles multi-stage hydraulic cylinders with precision and attention to detail. First, we meticulously assemble each stage to ensure that the pistons, rods and barrels are perfectly aligned. From the smallest seal to the largest metal bracket, each component is carefully assembled to ensure the quality of the cylinder.

In the final stage of assembly, we integrate the hydraulic system, connecting the ports and ensuring leak-tight seals. This integration is essential for the efficient and effective operation of the cylinders. We thoroughly test each assembled cylinder to verify its performance and durability.

If you are looking for high quality hydraulic cylinders, contact Topa, we are dedicated to providing one-stop hydraulic solutions to meet the specific needs of our customers in the hydraulics industry. Let us help you find the perfect hydraulic cylinders to drive your business forward.

Topa's Customized Services

Hydraulic Cylinder parts Production Topa

Topa offers specialized custom hydraulic cylinder services to meet your unique requirements.

Customization: We design cylinders to your specific dimensions, pressure ratings, and materials to ensure a perfect fit for your application.

Premium materials: We use only high-grade materials that are durable and provide superior performance. This ensures that your customized cylinder will stand up to the rigors of your application.

Expert engineering: Our skilled engineers work with you to realize your vision with expertise and innovation.

Rapid Production: From design to delivery, we work quickly to ensure your project is completed on schedule.

Rigorous Quality Assurance: Each custom cylinder is rigorously tested to ensure it meets our high standards and your expectations.

Professional Support: Our team provides ongoing support and advice to ensure your satisfaction throughout the process.

Choose Topa for your custom hydraulic cylinder needs, and we’ll meet all of your needs.
