Description:
71 Series fittings are compatible with hydraulic industry standards, constant working pressures and phosphate ester hoses. 71 Series fittings are available in a variety of end configurations from 3/8″ to 2″.
If you want free samples, please contact us.
Features and Benefits:
• No skive
• No leakage
• Easy installation and operation
• Quick assembly
• Stainless steel
Categories: hydraulic fittings, ORFS thread, Products
Part No. | 1- Hose Bore | 2- Thread | W- HEX (mm) | Dimensions | ||||
Size | Inch | DN | A(mm) | B(mm) | E(mm) | |||
TP71-06-06FF9 | 6 | 3/8″ | 10 | 11/16″-16 | 20.6 | 70 | 42 | 26 |
TP71-06-08FF9 | 6 | 3/8″ | 10 | 13/16″-16 | 23.8 | 70 | 42 | 28 |
TP71-08-06FF9 | 8 | 1/2″ | 12 | 11/16″-16 | 20.6 | 71 | 38 | 28 |
TP71-08-08FF9 | 8 | 1/2″ | 12 | 13/16″-16 | 23.8 | 71 | 38 | 30 |
TP71-12-10FF9 | 12 | 3/4″ | 20 | 1″-14 | 28.5 | 102 | 61 | 50 |
TP71-12-12FF9 | 12 | 3/4″ | 20 | 1.3/16″-12 | 34.9 | 102 | 61 | 49 |
TP71-16-16FF9 | 16 | 1″ | 25 | 1.7/16″-12 | 41.2 | 128 | 81 | 57 |
TP71-16-20FF9 | 16 | 1″ | 25 | 1.11/16″-12 | 47.6 | 128 | 81 | 60 |
TP71-20-16FF9 | 20 | 1.1/4″ | 32 | 1.7/16″-12 | 41.2 | 140 | 93 | 74 |
TP71-20-20FF9 | 20 | 1.1/4″ | 32 | 1.11/16″-12 | 47.6 | 140 | 93 | 77 |
TP71-20-24FF9 | 20 | 1.1/4″ | 32 | 2″-12 | 57.1 | 140 | 93 | 77 |
TP71-24-24FF9 | 24 | 1.1/2″ | 40 | 2″-12 | 57.1 | 151 | 91 | 80 |
This video is about the information of 1J971 ORFS hydraulic one-piece fitting. 1J971 ORFS one-piece hydraulic fittings have different dimensions and different sizes, they can used in lots of applications. If you need more information, please contact us.
Looking for unbeatable prices, top-tier quality, or custom solutions that fit your exact needs? Contact Topa Now！
“Still hesitating which product is right for you?” Send an inquiry and our hydraulics team will provide you with the best solution!
