Description:
Series 71 flange fittings are permanent fittings. Hydraulic flange connections are used in the most applications, as they are well suited for high pressure, shock and vibration. Flange hydraulic fittings allow easy and quick connection between hose and tube, without adding extra adapters.
If you want free samples or want to know more messages of flange hydraulic fitting, please contact us.
Features and Benefits:
• Multiple applications
• Easy connections
• Different materials
• Safe protection
• Stainless steel
Categories: hydraulic fittings, hydraulic flange, Products
Part No. | 1- Hose Bore | 2- Code 61 Flange size | Dimensions | |||||
Size | Inch | DN | A(mm) | B(mm) | F(mm) | |||
TP71-12-12C61 | 12 | 3/4″ | 20 | 3/4″ | 85 | 45 | 38.1 | |
TP71-12-16C61 | 12 | 3/4″ | 20 | 3/4″ | 81 | 41 | 44.4 | |
TP71-16-16C61 | 16 | 1″ | 25 | 1″ | 103 | 56 | 44.4 | |
TP71-16-20C61 | 16 | 1″ | 25 | 1″ | 101 | 54 | 50.8 | |
TP71-20-20C61 | 20 | 1.1/4″ | 32 | 1.1/4″ | 110 | 63 | 50.8 | |
TP71-20-24C61 | 20 | 1.1/4″ | 32 | 1.1/4″ | 116 | 69 | 60.3 | |
TP71-24-24C61 | 24 | 1.1/2″ | 40 | 1.1/2″ | 131 | 72 | 60.3 | |
TP71-24-32C61 | 24 | 1.1/2″ | 40 | 1.1/2″ | 138 | 79 | 71.4 | |
TP71-32-32C61 | 32 | 2″ | 50 | 2″ | 150 | 79 | 71.4 | |
This video is about 11571 flange hydraulic one-piece fitting. 11571 flange one-piece hydraulic fittings have many usages, they have lots of sizes and dimensions. And If you want more information about other products, please contact us.
Looking for unbeatable prices, top-tier quality, or custom solutions that fit your exact needs? Contact Topa Now！
“Still hesitating which product is right for you?” Send an inquiry and our hydraulics team will provide you with the best solution!
