Description
dash | inch | I.D mm | O.D mm | W.P bar | W.P psi | B.P bar | B.P psi | B.R mm | Length m | W.T kg/m |
-3 | 3/16″ | 4.8 | 14.0 | 415 | 6000 | 1660 | 24000 | 90 | 50-100 | 0.32 |
-4 | 1/4″ | 6.3 | 15.0 | 400 | 5800 | 1600 | 23200 | 100 | 50-100 | 0.38 |
-5 | 5/16″ | 7.9 | 16.5 | 350 | 5000 | 1400 | 20000 | 115 | 50-100 | 0.44 |
-6 | 3/8″ | 9.7 | 18.9 | 330 | 4800 | 1320 | 19200 | 125 | 50-100 | 0.54 |
-8 | 1/2″ | 12.7 | 22.0 | 275 | 4000 | 1100 | 16000 | 180 | 50-100 | 0.70 |
-10 | 5/8″ | 16 | 25.5 | 250 | 3600 | 1000 | 14400 | 205 | 50-100 | 0.80 |
-12 | 3/4″ | 19.1 | 29.3 | 215 | 3100 | 860 | 12400 | 240 | 50 | 0.95 |
-14 | 7/8″ | 22.2 | 32.0 | 200 | 3000 | 800 | 12000 | 260 | 50 | 1.20 |
-16 | 1″ | 25.4 | 35.5 | 165 | 2400 | 660 | 9600 | 300 | 50 | 1.32 |
-18 | 1.1/8″ | 28.6 | 39.0 | 140 | 2100 | 560 | 8400 | 380 | 60 | 1.65 |
-20 | 1.1/4″ | 31.8 | 44.3 | 125 | 1800 | 500 | 7200 | 420 | 60 | 1.95 |
-24 | 1.1/2″ | 38.1 | 50.3 | 90 | 1300 | 360 | 5200 | 500 | 60 | 2.20 |
-29 | 1.13/16″ | 46 | 59.0 | 85 | 1275 | 340 | 5100 | 580 | 60 | 2.46 |
-32 | 2″ | 50.8 | 63.8 | 80 | 1160 | 320 | 4640 | 630 | 60 | 2.78 |
Features
The 2 layer braided hydraulic hose is designed for high-pressure hydraulic systems that require stable performance and longer service life. Reinforced with two layers of high-tensile steel wire braid, it provides higher pressure resistance, improved impulse performance, and reliable operation under demanding working conditions.
The hose is suitable for construction machinery, agricultural equipment, industrial hydraulic systems, and heavy-duty applications. Its flexible structure supports easier installation in compact routing spaces while maintaining strong durability against abrasion, oil, weather, and pressure fluctuations. Custom sizes, colors, printing, and packaging are available for OEM and wholesale requirements.
Steam Hydraulic Hose Video
This video introduces the structure and performance of the steam hydraulic hose.
The hose is built with three layers: an EPDM inner tube, two layers of high-tensile steel wire braid reinforcement, and an IIR/EPDM outer cover. This structure provides stable pressure performance, heat resistance, flexibility, and reliable durability for steam transfer applications.
Topa steam hydraulic hoses are designed to support safe and efficient operation in demanding industrial working conditions.
If you need more information about steam hydraulic hoses, feel free to contact us for technical support and product details.
